Figure 38: BIOS Advanced Menu - FIA HSIO12 Configuration
BIOS SETUP UTILITY
Main Advanced Power Boot Security Save & Exit
Flexible I/O Adapter HSIO12 Configuration
HSIO12 I/O amount Full Avtive
Lane 8:PCIE-C6139(VGA) [PCIE Enabled]
Lane18:XHCI [XHCI Enabled]
Lane 0:PCIE-Soltx1 [Lane Disabled]
Lane12:I210-AT-1 [PCIE Enabled]
Lane14:I210-AT-2 [PCIE Enabled]
Lane10:mPCIE1/mSATA1 [JP1 with mPCIE]
Lane19:M.2 Key-B [SATA Enabled]
→ ←: Select Screen
Lane 9:SATA1 [SATA Enabled]
↑ ↓: Select Item
Lane11:SATA2 [SATA Enabled] Enter: Select
Lane13:SATA3 [SATA Enabled] +/-: Change Opt.
Lane15:SATA4 [SATA Enabled] F1: General Help
Lane16:SATA5 [SATA Enabled] F2: Previous Values
Lane17:SATA6 [SATA Enabled] F3: Optimized Defaults
F4: Save & Exit
mPCIE1 W-DISABLE# Pin [Enabled (Driven High)} ESC: Exit
Version 2.19.1266. Copyright (C) 2018, American Megatrends, Inc.
Feature Option Description
Lane 8:PCIE-
C6139(VGA)
[Lane Disabled], [PCIE
Enable]
Select Lane 8 to work as Disabled or PCIE-C6139(VGA).
Lane18:XHCI [Lane Disabled], [XHCI
Enabled]
Select Lane18 to work as Disabled or XHCI.
Lane 0:PCIE-Soltx1 [Lane Disabled], [PCIE
Enabled]
Select Lane 0 to work as Disabled or PCIE-Solt.
Lane12:I210-AT-1
Lane14:I210-AT-2
[Lane Disabled], [PCIE
Enabled]
Select Lane12 / Lane14 to work as Disabled or I210-AT-1 / I210-
AT-2 respectively.
Lane10:mPCIE1/mSAT
A1
[Lane Disabled], [PCIE
Enable], [SATA
Enable], [JP1 with
mPCIE]
Select Lane10 to work as Disabled, mPCIE1 or mSATA1.
Lane19:M.2 Key-B [Lane Disabled],
[SATA Enabled]
Select Lane19 to work as Disabled or M.2 Key-B.
Lane 9:SATA1
Lane11:SATA2
Lane13:SATA3
Lane15:SATA4
Lane16:SATA5
Lane17:SATA6
[Lane Disabled],
[SATA Enabled]
Select Lane 9 / Lane11 / Lane13 / Lane15 / Lane16 / Lane17 to
work as Disabled or SATA1 / SATA2 / SATA3 / SATA4 / SATA5 /
SATA6 respectively.
mPCIE1 W-DISABLE#
Pin
[Disabled (Driven
Low)], [Enabled
Select to control mPCIE1 W-DISABLE# signal Pin status. This
signal is used by the system to control radio operation on add-in
To Next Page
