Quanmax MITX-DNV0 Series User Manual

MITX-DNV0 Series - User Guide, Rev. 1.2
www.quanmax.com
// 76
Figure 52: BIOS Advanced Menu - H/W Monitor
BIOS SETUP UTILITY
Main Advanced Power Boot Security Save & Exit
PC Health Status
> Smart FAN Configuration
CPU Temperature-DTS : +31 C
CPU Temperature-Diode : +31 C
System Temperature : +34 C
CPU Fan Speed : 5818 RPM
→ ←: Select Screen
SYS Fan Speed : N/A
↑ ↓: Select Item
Enter: Select
+VCORE : +1.021 V +/-: Change Opt.
+12V : +11.956 V F1: General Help
+5V : +5.146 V F2: Previous Values
+VMEM : +1.221 V F3: Optimized Defaults
+3.3V : +3.392 V F4: Save & Exit
+VRTC : +3.184 V ESC: Exit
Version 2.19.1266. Copyright (C) 2018, American Megatrends, Inc.
BIOS SETUP UTILITY
Main Advanced Power Boot Security Save & Exit
Smart FAN Configuration
CPU FAN Setting [Manual]
→ ←: Select Screen
Manual Duty 255
↑ ↓: Select Item
Enter: Select
System FAN Setting [Manual] +/-: Change Opt.
Manual Duty 255 F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.19.1266. Copyright (C) 2018, American Megatrends, Inc.
Feature Option Description
CPU FAN Setting
System FAN Setting
[Manual], [Smart] Switch the CPU FAN control mode.

Quanmax MITX-DNV0 Series Specifications

General

Brand	Quanmax
Model	MITX-DNV0 Series
Category	Motherboard
Language	English
