Figure 40: BIOS Advanced Menu - SATA Configuration
BIOS SETUP UTILITY
Main Advanced Power Boot Security Save & Exit
SATA Configuration
SATA Controller 0 [Enabled]
SATA-0 Port Multiplier [Disabled]
SATA Controller 1 [Enabled]
SATA-1 Port Multiplier [Disabled]
Serial ATA Port 1 Empty
SATA1 [Enabled]
Serial ATA Port 2 Empty
SATA2 [Enabled]
Serial ATA Port 3 Empty
SATA3 [Enabled]
Serial ATA Port 4 Empty
→ ←: Select Screen
SATA4 [Enabled]
↑ ↓: Select Item
Serial ATA Port 5 Empty Enter: Select
SATA5 [Enabled] +/-: Change Opt.
Serial ATA Port 6 Empty F1: General Help
SATA6 [Enabled] F2: Previous Values
F3: Optimized Defaults
M.2 Key-B Empty F4: Save & Exit
M.2 SATA [Enabled] ESC: Exit
Version 2.19.1266. Copyright (C) 2018, American Megatrends, Inc.
Feature Option Description
SATA Controller 0
SATA Controller 1
[Enabled], [Disabled] Select whether to enable or disable SATA Controller0 / 1.
SATA-0 Port
Multiplier
SATA-1 Port Multiplier
[Enabled], [Disabled] Select whether to enable or disable SATA Controller 0 / 1 port
multiplier support in CAP register of the controller.
SATA1
SATA2
SATA3
SATA4
SATA5
SATA6
M.2 SATA
[Disabled], [Enabled] Select whether to enable or disable SATA1 / SATA2 / SATA3 /
SATA4 / SATA5 / SATA6 / M.2 SATA respectively.
