Quanmax MITX-DNV0 Series User Manual

MITX-DNV0 Series - User Guide, Rev. 1.2
www.quanmax.com
// 68
Figure 43: BIOS Advanced Menu - Network Stack Configuration
BIOS SETUP UTILITY
Main Advanced Power Boot Security Save & Exit
Network Stack Configuration
LAN Boot I210-AT-1 [Disabled]
→ ←: Select Screen
LAN Boot I210-AT-2 [Disabled]
↑ ↓: Select Item
LAN Boot X553 1GbE-1 [Disabled] Enter: Select
LAN Boot X553 1GbE-2 [Disabled] +/-: Change Opt.
LAN Boot X553 1GbE-3 [Disabled] F1: General Help
LAN Boot X553 1GbE-4 [Disabled] F2: Previous Values
F3: Optimized Defaults
Ipv4 PXE Support [Enabled] F4: Save & Exit
Ipv6 PXE Support [Disabled] ESC: Exit
Version 2.19.1266. Copyright (C) 2018, American Megatrends, Inc.
Feature Option Description
LAN Boot I210-AT-1
LAN Boot I210-AT-2
LAN Boot X553 1GbE-1
LAN Boot X553 1GbE-
2
LAN Boot X553 1GbE-
3
LAN Boot X553 1GbE-
4
[Disabled], [Load PXE] Select whether to enable or disable load onboard PXE (Preboot
Execution Environment) or uEFI-SNP (Simple Network Protocol).
Ipv4 PXE Support [Disabled], [Enabled] Select whether to enable or disable Ipv4 PXE boot support. If
disabled, Ipv4 PXE boot support will not be available.
Ipv6 PXE Support [Disabled], [Enabled] Select whether to enable or disable Ipv6 PXE boot support. If
disabled, Ipv6 PXE boot support will not be available.
