Sufficient cooling must be applied to the CPU in order to remove the effect as listed as TDP (Thermal Design Power) in
above table. The sufficient cooling is also depending on the worst case maximum ambient operating temperature and
the actual worst case load of processor.
3.6. System Memory Support
The MITX-DNV0 Series has two DDR4 UDIMM socket. The socket supports the following memory features:
 1x DDR4 UDIMM 288-pin (Atom™ C3338)
 2x DDR4 UDIMM 288-pin (Atom™ C3538)
 1866 / 2133 MHz memory speed
 SPD timing supported
 ECC supported
The installed DDR4 UDIMM should support the Serial Presence Detect (SPD) data structure. This allows the BIOS to
read and configure the memory controller for optimal performance. If non-SPD memory is used, the BIOS will attempt
to configure the memory settings, but performance and reliability may be impacted, or the board may not be able to
boot totally.
3.6.1. Memory Operating Frequencies
In all modes, the frequency of system memory is the lowest frequency of all the memory modules placed in the
system. Each memory module's frequency can be determined through the SPD registers on the memory modules.
The table below lists the resulting operating memory frequencies based on the combination of UDIMMs and
processor.
Table 5: Memory Operating Frequencies
SO-DIMM Type Module Name Memory Data
Transfer (MT/s)
Processor System
Bus Frequency
(MHz)
Resulting
Memory Clock
Frequency (MHz)
Peak Transfer
Rate (MB/s)
DDR4 1866 PC4-14900 1866.67 933.33 233.33 14933.33
DDR4 2133 PC4-17000 2133.33 1066.67 266.67 17066.67
Memory modules have in general a much lower longevity than embedded motherboards, and therefore EOL of
modules can be expected several times during lifetime of the motherboard.
As a minimum it is recommend using Quanmax memory modules for prototype system(s) in order to prove stability of
the system and as for reference.
For volume production you might request to test and qualify other types of RAM. In order to qualify RAM it is
recommend configuring 3 systems running RAM Stress Test program in heat chamber at 60° C for a minimum of 24
hours.
3.7. On-board Graphics Subsystem
The MITX-DNV0 Series integrates a VGA GPU based on the PCIe high-speed interface for small screen display
applications.
