MITX-DNV0 Series - User Guide, Rev. 1.2
www.quanmax.com
// 21
Table 6: Display Configuration
Display Max. Resolution (Px) at 60 Hz
VGA 1024 x 768
3.8. Power Supply
In order to ensure safe operation of the board, the input power supply must monitor the supply voltage and shut
down if the supply is out of range – refer to the actual power supply specification. Please note, in order to keep the
power consumption to a minimal level, boards do not implement a guaranteed minimum load. In some cases, this can
lead to compatibility problems with ATX power supplies that require a minimum load to stay in regulation. The MITX-
DNV0 Series board must be powered through the 24-pin ATX (24-pole) connector using standard ATX power supply.
ATX supply: ATX-24p connector must be used in according to the ATX PSU standard.
Hot Plugging power supply is not supported. Hot plugging might damage the board.
The requirements to the supply voltages are as follows:
Table 7: Supply Voltages
Supply Min. Max. Note
VCC3.3 3.135 V 3.265 V Should be ±5% for compliance with the ATX specification
Vcc 4.75 V 5.25 V Should be ±5% for compliance with the ATX specification.
Should be minimum 5.00 V measured at USB connectors in order to
meet the requirements of USB standard.
+12 V 11.4 V 12.6 V Should be ±5% for compliance with the ATX specification
-12 V -13.2 V -10.8 V Should be ±10% for compliance with the ATX specification
-5 V -5.50 V -4.5 V Should be ±10% for compliance with the ATX specification
5VSB 4.75 V 5.25 V Should be ±5% for compliance with the ATX specification
