MITX-DNV0 Series - User Guide, Rev. 1.2
www.quanmax.com
// 79
8.2.4. Boot Setup Menu
The boot setup menu lists the for boot device priority order, that is generated dynamically.
Figure 55: BIOS Boot Setup Menu
BIOS SETUP UTILITY
Main Advanced Power Boot Security Save & Exit
Boot Configuration
Full Screen LOGO Display [Disabled]
Setup Prompt Timeout 1
→ ←: Select Screen
Bootup NumLock State [On]
↑ ↓: Select Item
Enter: Select
CSM Support [Enabled] +/-: Change Opt.
Boot Option Filter [UEFI and Legacy] F1: General Help
Load build-in Shell [Enabled] F2: Previous Values
File System Drivers [Enabled] F3: Optimized Defaults
F4: Save & Exit
Boot Option Priorities ESC: Exit
Version 2.19.1266. Copyright (C) 2018, American Megatrends, Inc.
Feature Option Description
Full Screen LOGO
Display
[Disabled], [Enabled] Select whether to enable or disable to display logo screen.
Bootup NumLock
State
[On], [Off] Select the state of the NumLock feature of the keyboard after
Startup.
[On]: The keys on the keypad will act as numeric keys.
[Off]: The keys on the keypad will act as cursor keys.
CSM Support [Enabled] Select whether to enable or disable CSM support.
Boot Option Filter [UEFI and Legacy],
[Legacy only], [UEFI
only]
Control Legacy / UEFI ROMs priority.
Load build-in Shell [Enabled], [Disabled] It controls installation of the boot option for a built-in shell.
File System Drivers [Enabled], [Disabled] Free Software URFI File System Drivers, such as a read-only
NTFS or exFAT EFI drivers, courtesy of the GRUB project.
