Quanmax MITX-DNV0 Series User Manual

MITX-DNV0 Series - User Guide, Rev. 1.2
www.quanmax.com
// 70
Figure 45: BIOS Advanced Menu - Super IO Configuration
BIOS SETUP UTILITY
Main Advanced Power Boot Security Save & Exit
Super IO Configuration
> Serial Port 1 Configuration
→ ←: Select Screen
> Serial Port 2 Configuration
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.19.1266. Copyright (C) 2018, American Megatrends, Inc.
Figure 46: BIOS Advanced Menu - Super IO Configuration - Serial Port 1 Configuration
BIOS SETUP UTILITY
Main Advanced Power Boot Security Save & Exit
Serial Port 1 Configuration
Serial Port [Enabled]
→ ←: Select Screen
Device Settings IO=3F8h; IRQ=4;
↑ ↓: Select Item
Enter: Select
Change Setting [Auto] +/-: Change Opt.
Serial Port 1 Type [RS232] F1: General Help
RS485 Deplux Mode* [Half Duplex] F2: Previous Values
RS485 Auto Flow Control [Disabled] F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.19.1266. Copyright (C) 2018, American Megatrends, Inc.
* These items appear only when selecting RS485 for the Serial Port 1 Type.
Feature Option Description
Serial Port [Disabled], [Enabled] Select whether to enable or disable Serial Port (COM).
Change Settings [Auto], [IO=3F8h;
IRQ=4;], [IO=3F8h;
IRQ=3, 4, 5, 6, 7, 9, 10,
11, 12;], [IO=2F8h;
IRQ=3, 4, 5, 6, 7, 9, 10,
11, 12;], [IO=3E8h;
IRQ=3, 4, 5, 6, 7, 9, 10,
11, 12;], [IO=2E8h;
IRQ=3, 4, 5, 6, 7, 9, 10,
11, 12;]
Select an optional setting for Super IO device.
