Quanmax MITX-DNV0 Series User Manual

MITX-DNV0 Series - User Guide, Rev. 1.2
www.quanmax.com
// 74
Figure 50: BIOS Advanced Menu - Serial Port Console Redirection - Legacy Console Redirection Settings
BIOS SETUP UTILITY
Main Advanced Power Boot Security Save & Exit
Legacy Console Redirection Settings
Redirection COM Port [COM1]
→ ←: Select Screen
Resolution [80x24]
↑ ↓: Select Item
Redirect After POST [BootLoader] Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.19.1266. Copyright (C) 2018, American Megatrends, Inc.
Feature Option Description
Redirection COM Port [COM1], [COM2] Select a COM port to display redirection of Legacy OS abd
Legacy OPROM Messages.
Resolution [80x24], [80x25] Select the number of rows and columns supported redirection
on legacy OS.
Redirect After POST [Always Enabled],
[BootLoader]
When BootLoader is selected, legacy console redirection is
disabled before booting to legacy OS. When Always Enabled is
selected, legacy console redirection is enabled for legacy OS.
