Quanmax MITX-DNV0 Series User Manual

MITX-DNV0 Series - User Guide, Rev. 1.2
www.quanmax.com
// 23
Item Designation Description See Chapter
10 FAN2 System FAN Wafer 7.2
11 SATA1 SATA Port-1 Connector 7.3
12 SATA2 SATA Port-2 Connector 7.3
13 SATA3 SATA Port-3 Connector 7.3
14 SATA4 SATA Port-4 Connector 7.3
15 SATA5 SATA Port-5 Connector 7.3
16 SATA6 SATA Port-6 Connector 7.3
17 CN17 USB2.0 Port-1, 2 Header 7.4
18 FP1 Front Panel Header 1 7.5
19 FP2 Front Panel Header 2 7.5
20 CN16 RS-232/422/485 COM2 Wafer 7.6
21 CN15 8-bit Digital Input / Output Wafer 7.7
22 CN21 PS/2 KB/MS Wafer 7.8
23 M2B1 M.2 Key-B SSD Slot 7.9
24 MPCIE1 mPCIE / mSATA Port-1 Slot 7.10
25 CN4 SIM Interface Wafer for MPCIE1 7.11
26 PCIE1 PCIE x8 Slot 7.12
27 CN2 GbE LAN LED Header 7.13
28 CN5 Wireless Activity LED Header for MPCIE1 7.14
29 CN25 General Purpose LED Wafer 7.15
30 DIMM1 Channel-0 DDR4 DIMM Slot 3.6
31 DIMM2 Channel-1 DDR4 DIMM Slot 3.6
32 CN1 CR2032 Battery Holder
33 BZ1 Onboard Buzzer

Quanmax MITX-DNV0 Series Specifications

General

Brand	Quanmax
Model	MITX-DNV0 Series
Category	Motherboard
Language	English
