Quanmax MITX-DNV0 Series User Manual

MITX-DNV0 Series - User Guide, Rev. 1.2
www.quanmax.com
// 46
Pin Signal Note
26 Ground
27 Ground
28 +1.5V
29 Ground
30 SMB_CLK
31 PETn0 / SATA_TX-*
32 SMB_DATA
33 PETp0 / SATA_TX+*
34 Ground
35 Ground
36 USB_D-
37 Ground
38 USB_D+
39 +3.3VSB / +3.3V*
40 Ground
41 +3.3VSB / +3.3V*
42 LED_WWAN#
43 Ground / NC*
44 LED_WLAN#
45 Reserved
46 LED_WPAN#
47 Reserved
48 +1.5V
49 Reserved
50 Ground
51 Reserved
52 +3.3VSB / +3.3V*
* These pins are switchable to mSATA or mPCIe mode via the jumper JP1.
** These pins are connected to CN4 SIM Interface directly.
