Quanmax MITX-DNV0 Series User Manual

MITX-DNV0 Series - User Guide, Rev. 1.2
www.quanmax.com
// 49
Pin Side B Connector Side A Connector
Signal Description Signal Description
21 GND Ground PERp1 Receiver Lane 1, differential
pair
22 GND Ground PERn1
23 PETp2 Transmitter Lane 2,
differential pair
GND Ground
24 PETn2 GND Ground
25 GND Ground PERp2 Receiver Lane 2, differential
pair
26 GND Ground PERn2
27 PETp3 Transmitter Lane 3,
differential pair
GND Ground
28 PETn3 GND Ground
29 GND Ground PERp3 Receiver Lane 3, differential
pair
30 RSVD Reserved PERn3
31 PRSNT2# Hot plug presence detect GND Ground
32 GND Ground RSVD Reserved
33 PETp4 Transmitter Lane 4,
differential pair
RSVD Reserved
34 PETn4 GND Ground
35 GND Ground PERp4 Receiver Lane 4, differential
pair
36 GND Ground PERn4
37 PETp5 Transmitter Lane 5, differential
pair
GND Ground
38 PETn5 GND Ground
39 GND Ground PERp5 Receiver Lane 5, differential
pair
40 GND Ground PERn5
41 PETp6 Transmitter Lane 6,
differential pair
GND Ground
42 PETn6 GND Ground
43 GND Ground PERp6 Receiver Lane 6, differential
pair
44 GND Ground PERn6
45 PETp7 Transmitter Lane 7, differential
pair
GND Ground
46 PETn7 GND Ground
47 GND Ground PERp7 Receiver Lane 7, differential
pair
48 PRSNT2# Hot plug presence detect PERn7
49 GND Ground GND Ground
