Radioddity Extended manual for Radioddity DB25-D, DB40-D & GD-88 v3.0
© Radioddity 2023 page 89 of 252
(2) Modify Name → press the [Select]-key → modify the channel name → press
the [OK]-key to confirm and return to the previous level.
10.6 Local Set
If the basic operation and functions of the menu are allowed by software to set
and check, below functions are available thru accessing the Local Set menu.
10.6.1 Language
1. Access the menu, press the [Menu]-key and rotate the [ENC] knob or use the
[▲/▼]-keys to choose Local Set and then press the [Select]-key to enter.
2. Rotate the [ENC] knob or use the [▲/▼]-keys to choose the Language and
press the [Select]-key to enter.
3. Rotate the [ENC] knob or use the [▲/▼]-keys to choose the desired Language
and press the [Select]-key to change.
4. ‘Lang is Set’ pops up on the screen and return back to the previous level.
10.6.2 Keypadlock
1. Access the menu, press the [Menu]-key and rotate the [ENC] knob or use the
[▲/▼]-keys to choose Local Set and then press the [Select]-key to enter.
2. Rotate the [ENC] knob or use the [▲/▼]-keys to choose KeypadLock and press
the [Select]-key to enter.
3. Rotate the [ENC] knob or use the [▲/▼]-keys to choose the option of AutoLock
SW or ManualLock SW and press the [Select]-key to switch it On / Off.
4. Press the [Back]-key to return to the previous level.
10.6.3 Backlight
1. Press the preset [BackLight Auto/On/Off]-key.
or
1. Access the menu, press the [Menu]-key and rotate the [ENC] knob or use the
[▲/▼]-keys to choose Local Set and then press the [Select]-key to enter.
2. Rotate the [ENC] knob or use the [▲/▼]-keys to choose BackLight and press
the [Select]-key to choose from the following options:
(1) BL switch → press the [Select]-key → rotate the [ENC] knob or use the
[▲/▼]-keys to choose option of BL ON, BL OFF or Auto → press the [Select]-
key to confirm → return to the previous level.
To Next Page
