Radioddity Extended manual for Radioddity DB25-D, DB40-D & GD-88 v3.0
© Radioddity 2023 page 91 of 252
(4) VFO Mode → press the [Select]-key → VFO Mode is activated -> return
to standby screen.
Notes: This may also be accomplished by assigning a function key to
[VFO] and pressing that function key. For more details, please check
chapter 12.6 Preset Keys on page 140.
(5) S/D Mode → Press the [Select]-key to switch it On or Off → press the [Back]-
key to return to the previous level
Alternativey you can assign one of the programmable function keys for ‘Dual
Watch’.
Notes: For single VFO display, the switch should be to its On-position (green).
For dual VFO display, the switch should be to its Off-position (red).
If Dual VFO-mode is selected, only part of the Talker Alias data can be
displayed. Whereas if single VFO mode is selected more Talker Alias data
can be displayed.
10.6.6 VOX
1. Press the preset [VOX On/Off]-key to turn it On / Off.
or
1. Access the menu, press the [Menu]-key and rotate the [ENC] knob or use the
[▲/▼]-keys to choose Local Set and then press the [Select]-key to enter.
2. Rotate the [ENC] knob or use the [▲/▼]-keys to choose VOX and press the
[Select]-key to choose from the following options:
(1) Vox Switch → press the [Select]-key to turn it On or Off.
(2) Vox Level → press the [Select]-key → Rotate the [ENC] knob or use the
[▲/▼]-keys to choose the desired level between 1 and 12 → press the
