Radioddity Extended manual for Radioddity DB25-D, DB40-D & GD-88 v3.0
© Radioddity 2023 page 90 of 252
(2) Brightness → press the [Select]-key → rotate the [ENC] knob or use the
[▲/▼]-keys to select desired brightness between 0 and 6 → press the [OK]-
key to confirm → ‘Lightness is Set’ pops up on the screen → return to the
previous level.
(3) DelayTime → press the [Select]-key → rotate the [ENC] knob or use the
[▲/▼]-keys to select a value between 10 and 60 → press the [OK]-key to
confirm → ‘Set OK!’ pops up on the screen → return to the previous level.
10.6.4 LED indicator (LEDs)
1. Access the menu, press the [Menu]-key and rotate the [ENC] knob or use the
[▲/▼]-keys to choose Local Set and then press the [Select]-key to enter.
2. Rotate the [ENC] knob or use the [▲/▼]-keys to choose LEDs and press the
[Select]-key to enter.
3. Press the [Select]-key to switch it On or Off.
4. Press the [Back]-key to return to the previous level.
Notes: If the LED indicator is OFF, it will not light in receiving and transmitting.
If the LED indicator is On, it will light in receiving and transmitting.
10.6.5 DisplayMode
1. Access the menu, press the [Menu]-key and rotate the [ENC] knob or use the
[▲/▼]-keys to choose Local Set and then press the [Select]-key to enter.
2. Rotate the [ENC] knob or use the [▲/▼]-keys to choose DisplayMode and press
the [Select]-key to enter.
3. Rotate the [ENC] knob or use the [▲/▼]-keys to choose from the following
options:
(1) CHN+Name → press the [Select]-key for the display to show the channel
number and the name associated to it → ‘DispMode is Set’ pops up on the
screen → return to previous level.
(2) CHN+FREQ → press the [Select]-key for the display to show the channel
number and the frequency assigned to it →‘DispMode is Set’ pops up on
the screen → return to previous level.
(3) CHN → press the [Select]-key for the display to show just the channel
number →‘DispMode is Set’ pops up on the screen → return to previous
level.
