Remote Control Commands
R&S
®
NRPxxS(N)
110User Manual 1177.5079.02 ─ 10
Parameters:
<exclude_stop> Range: 0.0 to 1.0
*RST: 0.0
Default unit: Seconds
Manual operation: See "End Exclude" on page 46
See "End Exclude" on page 47
9.8.4 Configuring Corrections
It is possible to set some parameters that compensate for a change of the measured
signal due to fixed external influences.
● Duty Cycle Corrections..........................................................................................110
● Offset Corrections..................................................................................................111
● S-Parameter Correction.........................................................................................111
● S-Gamma Corrections...........................................................................................113
● Using the S-Parameters Tool................................................................................ 115
9.8.4.1 Duty Cycle Corrections
The duty cycle is the percentage of one period during which the signal is active, when
pulse-modulated signals are corrected. The duty cycle is only evaluated in the Continu-
ous Average mode.
Remote commands:
[SENSe<Sensor>:]CORRection:DCYCle.......................................................................... 110
[SENSe<Sensor>:]CORRection:DCYCle:STATe................................................................ 110
[SENSe<Sensor>:]CORRection:DCYCle <duty_cycle>
Available in continuous average mode.
Sets the duty cycle for measuring pulse-modulated signals. The duty cycle defines the
percentage of one period during which the signal is active. If the duty cycle is enabled,
the R&S NRPxxS(N) takes this percentage into account when calculating the signal
pulse power from the average power.
Parameters:
<duty_cycle> Range: 0.001 to 100.00
*RST: 1.00
Default unit: Percent
Manual operation: See "Duty Cycle" on page 45
[SENSe<Sensor>:]CORRection:DCYCle:STATe <state>
Enables or disables the duty cycle correction for the measured value.
Parameters:
<state> *RST: OFF
Configuring Basic Measurement Parameters
