Marker button: An incident can be highlighted in the Live Graph View.
This is synchronously saved with the data.
Settings button: This button opens the settings for the device.
Dialogue button: If messages with different priorities exist, the symbol
flashes in yellow or red. The message with the higher priority determines
the symbol’s colour. The figure in the speech bubble shows the number
of messages. See Section 4. Clicking the Dialogue button displays the
messages. The message in the menu pane applies to the entire device.
The message displayed in the separate measurement fields only applies
to this measuring position (see Figure 3).
3.3.4 Commonly occurring soft keys
