8 Technical Parameters (Specification)
8.1 Technical data
General information
Type designation:
RAUMED
®
NeuroSmart
®
REF 095284-001
RAUMED
®
NeuroSmart
®
logO REF 095294-001
Operating mode:
Continuous
Alarm volume:
Min. 70 dB(A) typically 75 dB(A), 1 m, in stand holder
Display:
LCD, colour, 10-inch
Trend display:
Selectable via menu
Alarm limits:
Selectable via menu
Dimensions:
Approx. 310 x 225 x 150 (W x L x D)
Mass:
Approx. 3 kg with battery
Data storage
3.3 GB (storage period up to 10 days)
Power supply:
Internal battery
Battery type:
Li-Ion (11.25 V / 2.95 Ah / 33.2 Wh)
Service life:
≥ 4 h (charged, battery as new, all channels occupied, @22 °C)
Charger / adapter:
Power adapter NeuroSmart (REF 284037-001)
Input: 100-240 V~ / 50-60 Hz / 600-300 mA,
Output: 15 V 󰂮 / 2 A, Protection Class II
Protection class:
Protection Class II with internal and external power supply
Type CF IEC 60601-1
Directive 90/385/EEC AIMD (in conjunction with Reader TDT1
readP)
93/42/EEC Class II b
IP type of protection:
IP 21 in use position (socket below, max. tilting
20°)
IP 2X: Protected against solid foreign objects with a diameter of
≥ 12.5 mm
IP X1: Protection from dripping water
Invasive temperature
Number of channels:
2
Measuring position designation:
T1, T2
Resolution:
0.01 °C
Measurement range:
15 ... 45 °C
Accuracy:
25 … 45 °C: ±0.1 K (plus sensor deviation ±0.1 K)
15 … 25 °C: ±0.2 K (plus sensor deviation ±0.2 K)
Sampling rate:
1 Hz
Defibrillator protection
Yes
This document is for information only
