Manual No. 016-0171-122 Rev. E 7
INTRODUCTION
Bracket - Rotary Sensor
Mounting
107-0172-1771111
Bracket - Rotary Sensor Bolt
Mounting
107-0172-1781111
Bracket - UltraGlide XT Valve
Mount
107-0172-1791111
Bracket - XT Rotary Sensor
Mounting
107-0172-2681111
Bracket - XT Sensor Mounting107-0172-3491111
Bracket - Ultrasonic Sensor
Weldment Mounting
116-0159-6841111
Cable - 70’ Sensor Extension 115-0171-527 2 2 2 2
Cable - AGCO RoGator Boom
Sense Adapter
115-0171-546 4 N/A 4 N/A
Cable - 40’ Sensor Extension 115-0171-602 2 2 2 2
Cable - AutoBoom Power 115-0233-007 1 N/A N/A N/A
TABLE 1. AutoBoom UltraGlide and UltraGlide XT Kit Contents
Picture Item Description Part Number
2009 Gen I
117-0233-010
Qty.
2009 Gen I
117-0234-010
Qty
2009 Gen II
117-0233-011
Qty.
2009 Gen II
117-0234-011
Qty.
