CHAPTER 2
8 Viper Pro Installation & Operation Manual
Cable - Deutsch Center Rack
Control Boom Sense Adapter
115-0230-039 2 N/A 2 N/A
Cable - 2 -in Deutsch Power
Split
115-0230-070 1 N/A 1 N/A
Cable - UltraGlide XT Node
Harness
115-0230-095 N/A N/A 1 1
Cable - UltraGlide XT Rotary
Sensor
115-0230-110 1 1 1 1
Cable - UltraGlide XT Valve
Harness
115-0230-116 1 1 N/A N/A
Cylinder - 1.5” x 8” x 0.75”
Hydraulic
334-0004-
006
2222
U-Bolt - 3-1/16” W x 4” L x 3/8”
Thread
107-0171-608 2 2 2 2
U-Bolt - 1-9/16” W x 2-1/2” L x
3/8” Thread
107-0171-611 8 N/A 8 N/A
U-Bolt - 2-9/16” W x 3-1/2” L x
3/8” Thread
107-0171-616 4 2 4 2
U-Bolt - 3-1/16” W x 2-1/4” L x
3/8” - 16 Thread
107-0172-2881111
TABLE 1. AutoBoom UltraGlide and UltraGlide XT Kit Contents
Picture Item Description Part Number
2009 Gen I
117-0233-010
Qty.
2009 Gen I
117-0234-010
Qty
2009 Gen II
117-0233-011
Qty.
2009 Gen II
117-0234-011
Qty.
