3
Manual No. 016-0171-122 Rev. E 33
HYDRAULIC SYSTEM INSTALLATION
FIGURE 19. Hydraulic Hose Installed
5. Connect the straight end of the installed hydraulic hose to the base-end of the installed right hydraulic cylinder.
FIGURE 20. Hose Installed on UltraGlide XT Valve
6. Install one end of the supplied hydraulic hose (P/N 214-1001-034) to the fitting installed in Port 2 of the
UltraGlide XT valve.
