Raven Command FLEX II User Manual

: Tip Selection and Application Speed Guide 105
• Table speeds are based on water-based carrier products. Changing to fertilizer-based products (which are more
dense) will decrease the minimum and maximum flow values displayed on the UT.
• Table speeds are based on 100% NCV efficiency. Higher or lower efficiencies will increase or decrease the
overall speed range on the UT.
• Table speeds do not account for any minimum and maximum flow offsets applied to individual NCVs.
STANDARD STYLE NOZZLE BODIES
TABLE 3. Standard Mode Speed Range (MPH) - 20” Spacing (3-8 GPA)
Tip
Size
Boom
(PSI)
2 GPA 3 GPA 5 GPA 8 GPA
Min Target Max Min Target Max Min Target Max Min Target Max
25% 40% 70% 100% 25% 40% 70% 100% 25% 40% 70% 100% 25% 40% 70% 100%
02
20 5.1 8.2 14.4 20.9 3.4 5.5 9.6 13.9 2.1 3.3 5.8 8.3 1.3 2.1 3.6 5.2
30 6.3 10.1 17.7 25.5 4.2 6.7 11.8 17.0 2.5 4.0 7.1 10.2 1.6 2.5 4.4 6.4
40 4.8 7.8 13.6 19.6 2.9 4.7 8.2 11.8 1.8 2.9 5.1 7.4
50 5.4 8.7 15.2 21.9 3.3 5.2 9.1 13.1 2.0 3.3 5.7 8.2
60
3.6 5.7 10.0 14.4 2.2 3.6 6.2 9.0
025
20 6.5 10.4 18.3 26.4 4.3 7.0 12.2 17.6 2.6 4.2 7.3 10.5 1.6 2.6 4.6 6.6
30
5.3 8.5 14.9 21.5 3.2 5.1 8.9 12.9 2.0 3.2 5.6 8.1
40 3.7 5.9 10.3 14.9 2.3 3.7 6.5 9.3
50
4.1 6.6 11.6 16.6 2.6 4.1 7.2 10.4
60 4.5 7.2 12.7 18.2 2.8 4.5 7.9 11.4
03
20 5.2 8.3 14.5 20.9 3.1 5.0 8.7 12.5 1.9 3.1 5.4 7.8
30 6.3 10.1 17.7 25.5 3.8 6.1 10.6 15.3 2.4 3.8 6.6 9.6
40
4.4 7.0 12.3 17.7 2.7 4.4 7.7 11.0
50 4.9 7.8 13.7 19.7 3.1 4.9 8.6 12.3
60
3.4 5.4 9.4 13.5
04
20 6.8 10.9 19.1 27.5 4.1 6.5 11.5 16.5 2.6 4.1 7.2 10.3
30
5.0 8.0 14.0 20.2 3.1 5.0 8.8 12.6
40 5.8 9.3 16.2 23.3 3.6 5.8 10.1 14.5
50
4.0 6.5 11.3 16.3
60 4.4 7.1 12.4 17.8
05
20 5.0 8.1 14.1 20.3 3.2 5.0 8.8 12.7
30 6.2 9.9 17.3 24.8 3.9 6.2 10.8 15.5
40
4.5 7.1 12.5 17.9
50 5.0 8.0 14.0 20.0
60
06
20 6.0 9.5 16.7 24.0 3.7 6.0 10.4 15.0
30
4.6 7.3 12.8 18.3
40 5.3 8.4 14.8 21.2
50
60
