6 RCM - Sprayer and AIM Command FLEX™ II Calibration and Operation Manual
RCM - SPRAYER FEATURES
OPERATION MODES
The RCM - Sprayer with AIM Command FLEX™ II control system can be configured in several different modes to fit
the application.
TABLE 1.
Operation Modes and Compatible Features
Modes of Operation
Conventional
/Bypass
On/
Off
Standard
Variable
Pressure (VP)
High
Flow
High
Flow VP
Compatible Features
Nozzle Used
Bypass NCV NCV NCV
NCV +
Bypass
NCV +
Bypass
Recommended
NCV Tip Size
1
NA 02-15 02-15 02-15 02-15 02-15
Speed Range
NA NA Good Best Good Best
Turn
Compensation
NA NA Good Best Good Best
Pressure
Control
2
Range Range Target Range Target Range
Coverage
Best Best Good Better Good Better
Direct Injection
3
Yes Yes Yes Yes Yes Yes
Wireless
Diagnostics
Yes Yes Yes Yes Yes Yes
Automated
Priming
4
Yes Yes Yes Yes Yes Yes
Product
Recirculation
5
No Yes Yes Yes No No
Droplet Indicator
Yes Yes Yes Yes Yes Yes
Air Induction Tip
Compatiblity
6
Yes Yes No No No No
Operating
Frequency
7
NA NA 20 Hz 20 Hz 20 Hz 20 Hz
Nozzle Flow
Offsets
8
No No Yes Yes Yes Yes
Individual
Nozzle Control
and Manual
Override NCV
Off
9
No Yes Yes Yes No No
Virtual
Sections
10
No Yes Yes Yes No No
