System Setup: System Settings Tab 35
SYSTEM SETUP
BOOM, SPARGE, PUMP, AND CENTER 1 & 2 PRESSURE SENSORS
Use the drop-down menus to select the proper operating range of the installed pressure transducer sensors.
Disconnecting the sensor and selecting None will disable the sensor and any alarms associated with it.
NOTE: A boom pressure transducer is required for system operation.
MINIMUM BOOM PRESSURE
The minimum boom pressure feature sets the lowest allowable boom pressure to which the product system will
control during applications. If the application system reaches the minimum pressure setting, the system will
maintain the flow rate to keep the monitored pressure consistent. This feature may be used to help maintain
boom pressure and the nozzle spray pattern if product application rates and equipment speeds are close to the
low end of the suggested ranges.
NOTE: Default minimum is 20 psi [137.9 kPa].
The minimum pressure feature may result in higher than desired application rates. If the minimum
pressure feature will be used during field applications, be sure to enter a value that will not interfere
with normal target rates or target pressures.
NOTE: Enable the minimum boom pressure alarm to enable an audible alarm when the minimum boom
pressure threshold is reached.
MAXIMUM PRESSURE
The maximum boom pressure feature sets the highest allowable boom pressure to which the product system will
control during applications. If the application system reaches the maximum pressure setting, the system will
maintain the flow rate to keep the monitored pressure consistent at or below the maximum pressure.
NOTE: The maximum pressure feature may result in lower than desired application rates. If the maximum
pressure feature will be used during field applications, be sure to enter a value that will not interfere
with normal target rates or target pressures.
NOTE: Enable the maximum boom pressure alarm to enable an audible alarm when the maximum boom
pressure threshold is reached.
The maximum recommended boom pressure for AIM Command FLEX™ II NCVs is 105 psi [724 kPa].
NCV INFORMATION
NOTE: NCV information and readings are not available in the Bypass NCV control mode.
To view NCV information:
1. Open the UT Menu and select the RCM - Sprayer Menu button.
2. Select the Tools Menu softkey along the right side of the display.
3. Select the System Settings tab along the top of the display.
RCM - Sprayer Menu Tools Menu System
Settings
UT Menu
NCV
Information
To Next Page
