Operation: Universal Terminal Definitions 51
OPERATION
QUICK ACCESS SOFTKEYS
The softkeys displayed along the right side of the RCM - Sprayer working set allow quick access to commonly used
features, calibration settings, and options. Review the following sections for additional information about the RCM
- Sprayer softkeys:
HOME
Touch the Home softkey to quickly return to the Home page and access the primary RCM - Sprayer
operation information. Use these pages to monitor the AIM Command FLEX™ II system during field
operations.
TOOLS
Select the Tools Menu softkey to access the calibration prompts. See Chapter 4, System Setup, for
additional assistance with system calibration, features, and settings.
TOTALS
Select Totals softkey to view the distance, volume, and area tallies calculated by the RCM - Sprayer
ECU. See Chapter 7, Totals, for additional assistance with the Totals features.
The totals button provides options to access a Current Totals, Device totals, and Distance totals
tabs.
DIAGNOSTICS
Select Diagnostics to access system information, tests, and diagnostic trouble codes (DTCs). Refer
to , NCV Diagnostics, for additional assistance with the AIM Command FLEX™ II NCV diagnostics
prompts.
The DTC Status indicator is displayed on the Diagnostics softkey and provides a visual indicator of
the system status during field applications. The status indicator provides the following display states:
Refer to Chapter 9, Troubleshooting, for additional assistance with diagnostic trouble codes and using the DTC list.
OK. The system status is normal and no alarm conditions are currently
present.
Caution. A minor alarm condition has been detected. The control system is
operating normally, however, the system has detected that a condition exists
which could impact the current application.
Critical. A critical system condition has been encountered. The control
system is not responding as expected and the operator should cease
application and troubleshoot the issue before resuming operations. The
system will not apply in this state
