CHAPTER
4
System Setup: Tools Menu Overview 21
CHAPTER 4
SYSTEM SETUP
TOOLS MENU OVERVIEW
System settings and options may be viewed by selecting the tabs displayed along the top of the Tools Menu.
NOTE: Touch the Help icon on any page for additional information.
Applicator Setup. Access the Applicator Setup page to edit or remove the RCM - Sprayer profile, review the
section and precision farming setup information, and configure other application system settings such as tip
size. Refer to Applicator Setup Tab section on page 22 for additional assistance with the Applicator Setup menu.
System Settings. Adjust the following product control settings and features:
Alarm Settings. Access alarm settings for each product control channel on the system.
Rates Setup. Enter product Rate and Pressure preset values, rate selection or enable the display smoothing
feature.
Feature Unlocks. Activate optional features of the Rate Control Module (RCM) - Sprayer control system. Contact a
local dealer for additional information regarding available features and to purchase feature unlocks.
• Control Valve Setup • Pressure Setup
• Rate Sensor Setup
•NCV Information
1
1. Not available in Bypass NCV control mode.
• Tank Fill Settings • User Settings
•Display Setup
Applicator Setup
Tab section on
page 22
System Settings
Tab section on
page 27
Alarm Settings
Tab section on
page 40
Rates Setup Tab
section on
page 42
Feature Unlocks
Tab section on
page 43
Tools
To Next Page
