CHAPTER 6
52 RCM - Sprayer and AIM Command FLEX™ II Calibration and Operation Manual
RCM - SPRAYER HOME PAGE FEATURES
FIGURE 2. Home Page Displays w/ Injection or Advanced Mode Activated
FIGURE 3. Home Page Displays w/o Injection or Basic View
Depending upon the mode and system options, the following display areas, information prompts, and features
may be accessible via the RCM - Sprayer home page:
Tabs
Readouts
Operation/
Performance
Display Data
Status and Control
Inputs
Readouts
Operation/
Performance
Display Data
