Raven Command FLEX II User Manual

: Flow meter Re-Calibration 111
SPECIFICATIONS BASED ON WATER
Flow Meter
Size
RFM 15P
(M200) Flange
RFM 60P
(M200) Flange
RFM 100P
(M220) Flange
RFM 200P
(M300) Flange
Pressure
Rating
175 psi
[1206.6 kPa]
175 psi
[1206.6 kPa]
150 psi
[1034.2 kPa]
125 psi
[861.8 kPa]
Normal Flow
Range
0.5 - 15 GPM
[1.9 - 56.8 L/min]
1.5 - 60 GPM
[5.7 - 227.1 L/min]
3 - 100 GPM
[11.4 - 378.5 L/min]
15 - 200 GPM
[56.8 - 757.1 L/min]
Pressure
Drop
3 psi @15 GPM
[20.7 kPa @
56.8 L/min]
5 psi @ 60 GPM
[34.5 kPa @
227.1 L/min]
3 psi @ 100 GPM
[20.7 kPa @
378.5 L/min]
4 psi @ 200 GPM
[27.6 kPa @
757.1 L/min]
Max Flow
Range
1
1. May reduce flow meter service life.
0.5 - 40 GPM
[1.9 - 151.4 L/min]
1.5 - 150 GPM
[5.7 - 567.8 L/min]
3 - 250 GPM
[11.4 - 946.4 L/min]
15 - 320 GPM
[56.8 - 1211.3 L/min]
Pressure
Drop
15 psi @ 40 GPM
[103.4 kPa @
151.4 L/min]
35 psi @ 150 GPM
[241.3 kPa @
567.8 L/min]
16 psi @ 250GPM
[110.3 kPa @
946.4 L/min]
9 psi @ 320 GPM
[62.1 kPa @
1211.3 L/min]
