System Setup: Feature Unlocks Tab 43
SYSTEM SETUP
RATIO RATE
NOTE: The ratio rate feature is available only when direct injection is detected.
Enable the Ratio Rate feature to maintain a ratio of direct injection flow into the carrier flow based on the carrier
flow meter reading. When the ratio rate is disabled, the direct injection flow is based upon the target application
rate of the direct injection product, independent of the carrier target application rate.
NOTE: The Ratio Rate option should only be checked when the injected chemical label specifically calls out a
volume per volume ratio of chemical to carrier (e.g. oz/gal or mL/L) instead of volume of chemical per
applied area (e.g. oz/acre or mL/Ha).
FEATURE UNLOCKS TAB
The Feature Unlocks tab allows the operator to review the status of optional features of the nozzle control system
or activate additional features using an activation key. Unlocked features are visible on the Feature Unlocks page.
NOTE: Contact a local Case IH dealer for additional information regarding available features or to acquire
activation keys.
ENTER ACTIVATION KEYS
To access the Feature Unlocks tab:
1. Open the UT Menu and select the RCM - Sprayer Menu button.
2. Select the Tools Menu softkey along the right side of the display.
3. Select the Feature Unlocks tab along the top of the page.
4. Touch the Activation Key field and use the on-screen keyboard to enter the code purchased from your local
Case IH dealer.
NOTE: Also displays features already unlocked for use with the RCM - Sprayer system.
RCM - Sprayer Menu Tools Menu Feature
Unlocks
UT Menu
To Next Page
