Raven Command FLEX II User Manual

CHAPTER 9
86 RCM - Sprayer and AIM Command FLEX™ II Calibration and Operation Manual
TABLE 1.
LED Status
LED Indicator
State
LED Color Flash Rate
Power Green Solid ECU is powered on.
A
Off Solid Microprocessor is not powered.
Any Solid Microprocessor has stopped functioning.
Yellow 1 Active when the boot loader enters boot hold mode.
Red
5 Active when the microprocessor is being programmed.
1 Active if the ISOBUS is offline.
White 1 Active if the UT is offline.
Purple 1 Loop back test mode enabled.
Green 1 Active when linked with UT and system is normal.
B
Red
Solid PCB subsystem not running (FPGA).
1 System has lost ECU power.
Blue 1 Signal is present on 1 or more rate sensors.
Yellow 1 One or more DTCs are active.
White 1 System voltage is below 11.5 volts.
Purple 1 System voltage is above 16 volts.
Blue Solid One or more product switches have been set to On.
Purple Solid Signal is present on one or more RPM sensors.
Green Solid All product switches have been set to Off.
Red Solid
One or more loop back subtests failed in this current test
sequence.
Yellow Solid
One or more loop back subtests failed in the previous
test sequence.
Green Solid No loop back subtests have failed.
C
Red Solid PCB subsystem not running (FPGA).
Blue 1 Bluetooth command has been received.
Blue Solid Bluetooth communication is active.
Green 1 The Auxiliary CAN channel is active.
Red 1
Active if the Auxiliary CAN channel was active and is now
offline.
Green Solid
LED C is functional and there are no other LED C states
to report.
Purple Solid A loop back test is in progress.
Green Solid A loop back test is not in progress.
