Raycus XZ Series User Manual

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C20000TZ
6
b) The laser output head is connected with fiber optic cable. Please inspect the output head
carefully for dust or other contaminations. Use appropriate lens paper to clean it if necessary.
c) Failure to follow the instructions when operating the laser may cause malfunction and damage.
d) It is not allowed to install the output head when the laser is in operation.
e) Do not look into the output head directly. Wear appropriate protective eye glasses all the time
when operating the laser.
Tips: Install the laser in an air-conditioned environment for longer life and better performance.
2.5 Attentions
a) Make sure that the correct voltage of 380VAC is used. Connecting failure of power supply will
damage the device.
b) The output laser is collimated by the collimating lens, it is important to keep the collimating
lens clean, otherwise it will damage the device.
c) Please cap the output head when it is not in use. Do not touch the output lens at any time. Use
appropriate lens paper to clean it if necessary.
d) Safety keep the cap when using the laser. To avoid dust, make sure the opening direction of the
cap is put down.
e) Failure to follow the instructions may cause laser power loss, such loss is not covered by
warranty.
2.6 Features
The optical, electrical and other properties of RFL-C4000XZ~ RFL-C20000TZ lasers are listed in
Table 2.
Table 2 Product technical data sheet
Optical properties
Type
C4000XZ
C6000XZ
C8000XZ
C10000XZ
C12000
XZ(XC)
C12000
TZ(TC)
C15000TZ
C20000TZ
Output
Power(kW)
4
6
8
10
12
15
20
Operation
Mode
CW/Modulated
Polarization
State
Random
Output Power
Tunability
(%)
10~100
Emission
Wavelength
1080±5 (Nominal Output Power)
