Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C20000TZ
INDICATOR LIGHT: After the main power supply of the laser is powered on, the green indicator
light is on when the laser is Ready; when the laser is emitting light, the red indicator light is on; when the
laser has a fault, the yellow indicator light is on, accompanied by an alarm sound.
4.2 Rear Panel
Figure 13 shows the rear panel (take C20000TZ as an example).
Figure 13 Rear view of product panel
Note: ①- INTERFACE ②-BREAKER ③-AC INPUT
④-FIBER WATER IN ⑤-FIBER WATER OUT ⑥- WATER OUT
