Raycus XZ Series User Manual

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C20000TZ
42
5.6.4 Programming Mode
When A1 of XP1 is set high and A8-A14 is not 0, the laser is in “Programming Mode”. At this
time, the laser emission is controlled by A2 of XP1, and the laser emission waveform is determined
by the edited waveform.
6 Laser Wiring Diagram and Operation Steps
6.1 Internal Control in ON Mode
XP3(Serial Interface)
XP5(Ethernet Interface)
AC INPUT
XP2
(Security Interface)
PC
AC POWER
~380VAC
L1
L2
L3
PE
17
18
19
20
Ethernet cable
Interlock1
Interlock2
Serial port line
Raycus Laser
Figure 18 Software mode wiring diagram when key switch at “ON” position
Operations Steps
a) Turn the knob switch on the rear panel to“ON”
b) Turn the key switch to“ON”
c) Open the Raycus PC software
d) Click the guide laser “ON” button to view the guide laser
e) Turn off “AD” mode and turn off external control mode (this mode can be memorized when
power off)
f) Click the main power “ON”
g) Waiting for “Ready”
h) Set laser emission parameters
i) Click the laser “ON”.
