3.2 Installation Rule
a) Place the laser horizontally in a suitable position and fix it as necessary;
b) Before the laser is powered on, Please check if the power supply has the correct voltage
(380VAC±10%, 50/60Hz, See “Table 2 Product technical data sheet” for details.), whether the
grounding line is well grounded;
c) Connect the power cable and control cable to the product when power supply is OFF;
d) Connect the cooling system to the laser and output optical cable head according to the water
inlet and outlet signs;
e) Please check the laser output head and make sure to clean it before installing it in the
equipment;
f) Do not step on, squeeze or excessively bend the protective tube during the installation of the
output optical cable to avoid damage to the optical fiber;
g) In the process of installing the optical cable output head, ensure the cleanliness of the
surrounding environment (do not use electric fans to dissipate heat when it is hot in summer to
avoid large dust in the air);
h) The minimum bending diameter of the laser transmission cable in non-working conditions such
as transportation and storage shall not be less than 40cm. When the laser is emitting light, the
minimum bending diameter shall not be less than 60cm;
i) Customers can use the four lifting rings at the top of the product or the four casters at the
bottom to lift or move the product. Before lifting the laser source, make sure that the four lifting
rings are installed firmly and reliably. When lifting the laser source, be sure to use the four
lifting rings; when pushing the laser source, please make sure that the support block at the
bottom of the horizontal adjustment caster is off the ground. After the laser source is positioned,
adjust the support block to make it contact the ground to avoid displacement of the laser source.
As shown in Figure 4(Take C20000TZ as an example).
