5.2 AD Enable Mode
When AD mode is enabled, the laser power is determined by the analog voltage of pin 1 and pin
2 of XP4. If the AD mode is not enabled, the laser power can be set through the PC software or send
the “SDC XX” command.
5.3 Emission External Control Enable
When the emission external control is enabled, the laser emission is determined by the level
difference between the pins of MOD+ and MOD- in the XP2 port; if the emission external control is
not enabled, the laser emission or shutdown are determined by the emit button on the PC software.
Also, you can send “EMON” command to turn laser emission on, and send “EMOFF” command to
turn laser emission off.
5.4 Guide Laser (Red Guide Beam) Control
In “ON” mode guide laser can only be turned on/off by using PC software, or by sending
command of “ABN” (on) / “ABF” (off).
The red light module inside the laser works through communication, so there is a time delay of
at least 10ms for the opening and closing of red light；
When the red light is on, the laser cannot be set to “Ready”. Only after the red light is turned off
the laser can be set to “Ready”. (This limit can be changed, please contact Raycus Engineer).
5.5 Programming Mode
In “ON” mode, when the current program number of the laser is not 0, the laser runs in the
“Programming” mode. Please use the Raycus PC software to edit the waveform and select the pre-run
program number.
When the laser is in the internal control mode:
Send the “EMON” command or press the “ON”
button, the laser will start to run the program,
