Raycus XZ Series User Manual

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C20000TZ
35
4.4.3 Serial RS232 Interface
The 9-pin serial interface RS232 is used for the communication between the laser and the upper
computer. It can be used to communicate with the PC software of Raycus or the software of the upper
computer which integrates the communication protocol of Raycus. The definition is as follows.
Table 8 RS232 serial interface definition
Pin No.
Type
Description
2
IN
RXD, serial receiving pin of laser
3
OUT
TXD, serial transmitting pin of laser
5
COM
GND, signal ground
4.4.4 Analog Interface XP4
The analog interface, an 8-core Harting interface, is used to control the output power of the laser by
analog in AD mode, and can also monitor the output light and power feedback signals of the laser. The
interface definition is shown in Table 9 below.
Table 9 XP4 analog interface definition
Pin No.
Type
Description
1
IN
0V~10 V analog signal, laser power control signal in AD mode ,
0V~10 V corresponding to 0%~100% output power
2
AGND
Analog signal ground
3
OUT
Power amplifier voltage output.
0 V: 0% laser power output;
8 V: 100% laser power output.
4
Reference
Reference ground for power amplifier voltage
5
OUT
High back-amplification voltage (reserve, no use)
6
Reference
Reference ground for high backup voltage (reserve, no use)
4.4.5 ETHERNET Interface XP5
Table 10 XP5 communication interface definition
Pin No.
Function
Description
1
TX+
Data transmission+
2
TX-
Data transmission-
3
RX+
Data acceptance+
4
N/C
Not connect
5
N/C
Not connect
6
RX-
Data acceptance-
7
N/C
Not connect
8
N/C
Not connect
