User Guide of RFL-C20000TZ
34
B9
Program running
Output signal
Laser program is running when B9 is high.
B10
Program ending
Output signal
Laser program is ended when B10 is high. B10 clears
when the A2 is invalid.
B11
Abnormal Wave
Mode Termination
Output signal
Laser program is ended abnormally when B11 is high.
B11 can be cleared when the A4 is high.
B12
Synchronous
output
Output signal
Sync signal output in programming mode.
B13
Warning output
Output signal
Laser is warning when B13 is high.
B14
Not connect
B15
External power
supply (Positive
pole)
Input signal
The 24 V input voltage, power supply of all XP1
output signal. Only when B15 and B16 access
24 V power, output signal is effective.
B16
External power
(Negative pole)
Input signal
D1~D4
Current optical
gate channel
Output signal
Indicates the current optical gate channel:
0000-all optical gate channels closed;
0001-channel1 opened;
0010-channel 2 opened;
0011-channel 3 opened.
D1 is the lowest bit, D4 is the highest bit.
(For lasers with optical gate channels only, these pins
are spare in other lasers)
D5
Water cooler
warning
Output signal
Indicates the current water temperature warning,
indicating a risk of emitting laser.
(Used with Water Cooler)
D6
Water cooler alarm
Output signal
Indicates the current water temperature alarm,
prohibits laser emission.
(Used with Water Cooler)
D7
QCW mode
Output signal
Output signal indicating that the current laser operates
in QCW mode
(For lasers with QCW mode only)
D8~D11
Laser hardwire
address
Output signal
Set the laser hardwire address (Coding-Cable
function):
0000- laser 0;
0001- laser1.
D8 is the lowest bit, D11 is the highest bit.
D12~D16
Not connect
