Raycus XZ Series User Manual

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C20000TZ
33
A7
Stop programming
Mode
Input signal
In programming mode, program execution is
terminated immediately when A7 is high.
A8~A14
Set program
Number
Input signal
Hardwired address for selecting a stored program
number. A8 is the lowest bit and A14 is the
highest bit.
A15
synchronous input
Input signal
Synchronous input signal, used with the program
command WAIT in programming mode.
A16
COM
Reference
ground
Reference ground for all input signals of XP1.
C1
Laser-driven
power supply
Input signal
The rising edge turns on the main power, and the
falling edge turns off the main power.
XP1
C2
Not connect
C3~C6
Select the optical
gate channel
Input signal
C3 is the lowest bit, C6 is the highest bit:
0000-close all optical gate channels;
0001-open channel 1;
0010-open channel 2;
0011-open channel 3.
(For lasers with optical gate channels only, these pins
are spare in other lasers)
C7
Enable QCW
mode
Input signal
Enable QCW mode
(For lasers with QCW modes only)
C8~C16
Not connect
B1
The laser is ready
Output signal
The laser is ready to emit laser light when B1 is high.
B2
Laser output
Output signal
The laser is emitting light when B2 is high.
B3
The laser operates
in internal mode
Output signal
The laser works in the internal control mode when B3
is high. In this mode, the laser can be controlled
by communication.
B4
Laser anomalies
Output signal
The laser is abnormal when B4 is high.
B5
Laser red light
indication
Output signal
The laser is emitting guide light when B5 is high.
B6
AD mode
Output signal
The laser works in the AD mode when B6 is high.
B7
Feedback signal of
A1
Output signal
The laser has received the A1 signal when B7 is high.
B8
Main power
supply of laser
Output signal
The main power of laser is on when B8 is high.
