Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C20000TZ
(a) Power cord of 4kW laser (b) Power cord of 6kW laser
(c) Power cord of 8kW/10kW/12kW laser (d) Power cord of 15kW/20kW laser
Figure 14 Power cords
Insert the plug at the end of the power cord into the socket marked "AC INPUT" on the rear panel.
Note that the plug has an anti-reverse connection function. After inserting it, use the lock to lock the plug
and socket as shown in Figure 15.
(a) Power cord plug and socket of 4kW laser
