Chapter 5: Standard Chart Operations 5-11
Editing the
Waypoint Details
➤ To display the waypoint data box, move the cursor over the waypoint.
The waypoint data box is displayed, this indicates waypoint number/name,
bearing and range (or latitude and longitude if selected in the system set up
menu).
While the cursor is over the waypoint, the waypoint soft keys are displayed.
➤ To remove the waypoint data box and soft keys either:
Move the cursor away from the waypoint, or press CLEAR.
➤ To display the waypoint details from the waypoint list:
Select the waypoint in the list as described above.
The details for the selected waypoint are displayed in the lower half of the
window. Temperature, depth, date and time are included (if available) for
waypoints placed at the vessel position.
To remove the Waypoint List and return to the default soft key display, press
CLEAR twice.
Editing the Waypoint Details
You can change the name, symbol and position of any waypoint.
➤ To edit a waypoint:
1. Select the waypoint, using the cursor or the waypoint list, as previously
described. The waypoint soft keys are displayed.
2. Press the
EDIT WAYPOINT
soft key. The Edit Waypoint soft keys are dis-
played:
3. To edit the symbol, press the
SYMBOL
soft key.
Use the soft keys, shown in the following illustration, to highlight the
required symbol, then press ENTER to confirm the selection.
Press ENTER or CLEAR to return to the default soft keys.
D4250-1
BRG 191
o
T
RNG 2.2nm
WAYPOINT 001
MARKS
WAYPOINT
LIST
EDIT
WAYPOINT
D4166-1
SYMBOL NAME POSITION
SELECT SYMBOL
D4178-1
