Chapter 1: Overview 1-3
General
A summary of the radar and chartplotter controls are provided on the Quick
Reference Cards supplied with your system.
Terminology
The following terminology is used to describe radar and chartplotter systems:
Master A unit capable of sourcing specific data such as
fishfinder, chart or radar data.
Repeater A unit capable of displaying data, such as radar, from
the HSB.
Fishfinder Display Unit providing Fishfinder Master and Radar Repeater
functionality. The L755 and L760 displays also
provide Chart Master functionality.
Radar Display Unit providing Radar Master, Fishfinder Repeater
and Chart Repeater functionality.
Chart Display Unit providing Chart Master, Fishfinder Repeater and
Radar Repeater functionality.
Combined DisplayUnit providing both Fishfinder and Chart or Radar and
Chart Master functionality.
Integrated System Additional instruments are connected via the HSB,
Seatalk or NMEA interfaces.
HSB™ High Speed Bus - links compatible display units.
For full display and control between HSB Series display
units, the units must be connected via HSB and SeaTalk.
General
The HSB Series Pathfinder Radar or Pathfinder Radar/Chartplotter, illustrated
below, comprises the 7"or 10.4" Color LCD display unit, scanner unit and
associated cables. The RC530 and RC631 Chartplotters cannot be connected
to the scanner unit.
