Chapter 2: Getting Started & Adjusting the Display 2-13
Customizing the
Screen Presentation
Options
Customizing the Screen Presentation Options
The
SCREEN
soft key lets you set the following screen presentation options on
or off:
Radar:
Chart:
Switching the Cursor Data Box On and Off
The cursor data box provides the cursor’s position in latitude/longitude and/or
bearing/range. If you wish to see a full image, you can switch the data box off.
➤ To control the cursor data box:
1. Press the
SCREEN
soft key.
2. Press the
CRSR BOX
soft key to toggle the setting from
OFF
to
ON
or from
ON
to
OFF
.
3. To return to the default soft key display, press
ENTER
.
➤ You can move the cursor data box using the context-sensitive cursor.
Switching Radar Range Rings or Chart Grid On and Off
The radar range rings can be turned on or off. They are normally left on, but
you may wish to turn them off if you are using VRM/EBLs or guard zones (see
Section 3.4 and Section 3.5) to make the display clearer.
The Chartplotter display includes grid lines of latitude and longitude which
you can use to help determine position on the chart. The grid lines can be
switched on if required.
If you are in Chart mode the
RNGE RNGS
soft key is replaced by the
CHRT GRID
soft key.
➤ To turn the range rings or chart grid on or off:
1. Press the
SCREEN
default soft key.
2. Press the
RANGE RINGS
or the
CHRT GRID
soft key to toggle the setting from
OFF
to
ON
or from
ON
to
OFF
.
