Chapter 6: Further Chart Operations 6-7
Cursor Echo
➤ To cancel the MOB, press and hold the MARKS key for 2 seconds.
The chart is re-drawn at its previous scale, and the MOB symbol and data box
are removed.
Note: The MOB procedure can also be initiated or cancelled if the appropri-
ate SeaTalk message is received by the display unit.
6.5 Cursor Echo
In a combined radar/chart display, or in a system with a radar display
connected via SeaTalk, you can set the display to enable cursor echo. Cursor
echo (accessed from System Set Up, described in Section 7.3) enables you to
display a radar cursor on the chart picture, or a chart cursor on the radar picture
(you cannot display a remote chart cursor in a chart window nor a remote radar
cursor in a radar window).
The following options can be toggled
ON
or
OFF
:
• Radar Cursor In: displays the cursor from another radar on the chart dis-
play or chart window (default -
OFF
).
• Chart Cursor In: displays the cursor from another or chartplotter on the
radar display or radar window (default -
OFF
).
Note: The remote display must have SeaTalk Cursor Out enabled.
• SeaTalk Cursor Out: enables the output, onto SeaTalk, of the display’s
own cursor (default -
OFF
).
• Cursor Echo Local: echoes the cursor position between open windows on
the same display (default -
ON
).
If you set the options to
OFF
, no cursor echo information is displayed.
When the appropriate option is switched on, the display shows its own cursor,
plus the cursor of the other display with appropriate cursor text (
RDR
or
CHT
) to
indicate its origin. This means that you could move the cursor over a target on
the radar display, and check the identity of the target by looking at the radar
cursor position on the chartplotter.
MARKS
