Appendix C: C-MAP Chart Card Features C-1
Appendix C:C-MAP
Chart Card Features
Appendix C:C-MAP Chart Card Features
The C_MAP chart cards display cartographic features which are derived from
a library of symbols. The library includes a set of 16 x 16 pixel bitmaps which
provide realistically shaped icons for many chart objects. However, these
complex icons can overlap and clutter the display at some scales, so it possible
for the user to select smaller, simple icons. Some chart objects are represented
by text; in such cases conventional abbreviated text is used, for example, M –
mud, R – rock, Wk – wreck
.
The chartplotter RC520 and RL70RC set up menu provides the sub-menu
CUSTOMISE CHART
, which lets you determine how chart features are displayed.
You can set the icon display of many features to custom; you then use the
CUSTOM
soft key to switch the customized icons off/on. The factory default for
the
CUSTOM
options is on.
The chart features controlled from the Customize Chart menu are grouped as
detailed below, some groups are sub-divided into categories
Menu Option Chart Features
CHART TEXT Names
CHART BOUNDARIES Chart Boundaries
SPOT SOUNDINGS Spot Soundings
DEPTH SHADING LIMIT Reference Depth
DEPTH CONTOURS Depths (Bathymetric Lines)
Depth Labels
DEPTH CONTOUR DIS-
PLAY
Depth Contour
Range
