7-10 HSB Series Color LCD Display
Radar Set Up
Parameters
• Radar provides simulated radar picture, with example targets. The pic-
ture does not change if you change the range, although the range rings are
adjusted (see Chapter 3)
.
• Both provides simulated data and radar picture.
When the simulator is switched on, a
SIMULATOR
data box is displayed during
operation, showing the simulation selected.
7.4 Radar Set Up Parameters
The
RADAR SET UP
option allows you to set up the radar according to your
system configuration and your personal preferences.
Note: Some parameters can only be changed if you are using the Master dis-
play (that is, the display to which the scanner is connected).
The following table lists the Radar Set Up parameters and their options,
shows the factory default setting, and provides a space for you to make a
note of your new default setting. Each parameter is described in the fol-
lowing subsections.
EBL Display
The mode of the bearing data displayed for Electronic Bearing Lines
(EBLs). The bearing information can be displayed in either of two forms:
• Relative: The bearing relative to your vessel’s heading.
Table 7-2: Radar Set Up Parameters
Parameter Options Factory Default New Default
EBL DISPLAY MAG/TRUE, RELATIVE RELATIVE
TIMED
TRANSMISSION
OFF, ON OFF
TRANSMIT PERIOD 10 scans, 20 scans, 30 scans 20 scans
STANDBY PERIOD 3, 5, 10 or 15 mins 10 minutes
DEFAULT MARK
SYMBOL , , ,
MARK DISPLAY OFF, ON ffN
CLEAR MARKS Press soft key to clear marks
database
N/A
CUSTOM SCALE OFF, ON,SET RANGES... OFF
BEARING
ALIGNMENT
Slider value 0°
