Raymarine hsb2 - Radar System Checks and Adjustments

Chapter 8: Installation 8-17
Radar System
Checks and
Adjustments
Figure 8-9: System Set Up Menu
3. Use the trackpad to move the selection bar down to the
LANGUAGE
option.
the soft key labels are updated.
4. Use the soft keys to highlight the required language.
5. Press ENTER to return to the setup soft keys.
6. Press CLEAR to return to the normal radar screen.
Radar System Checks and Adjustments
When the display is connected to a scanner unit you should perform the checks
and adjustments detailed below.
Transmission Check
WARNING:
The radar scanner transmits electromagnetic energy. Ensure that the
scanner has been installed according to the recommendations given in the
Pathfinder Radar Scanner Owner’s Handbook,
and that all personnel are
clear of the scanner, before switching to transmit mode.
Ensure the display unit is in Radar mode.
