6-4 HSB Series Color LCD Display
Alarms and Timers
6.3 Alarms and Timers
Alarm Reporting
The chartplotter reports the following alarms, that are set using the
ALARMS
key:
Alarm Indicates:
Arrival Your vessel has arrived at the active waypoint: it has either
reached the arrival circle (the radius of which is specified) or,
has reached its closest point of approach (defined by a line
passing through the waypoint and perpendicular to the route
leg).
Off Course Your vessel has exceeded the specified distance (maximum
cross track error) from the active route leg.
Anchor Your vessel has drifted from its anchor position (set when the
alarm was turned on) by more than the specified distance.
Countdown The countdown timer has reached zero.
Alarm Clock The time matches the specified alarm time.
The alarms are switched on or off, and the limits set, using the Alarms Set Up
menu, accessed from the
ALARMS
key.
When an alarm is triggered, the alarm buzzer sounds and a pop-up window
describing the alarm is displayed.
➤ To silence the alarm and clear the message, press any key.
If the alarm was generated by the chartplotter, the appropriate action is taken.
For example, following an arrival alarm, the next route leg is activated.
External Alarms
All SeaTalk system alarms (except autopilot alarms) are received and
displayed on the chartplotter. You can silence these alarms by pressing any
key. No other action is taken by the chartplotter except to silence the alarm.
Setting Alarms and Timers
➤ To set up an alarm or timer:
1. Press the
ALARMS
key. The Alarms Set Up menu is displayed, showing
the current settings (see Figure 6-2).
2. Use the trackpad to move the selection bar up or down the options. As each
line is highlighted, the soft key labels are updated to show the current set-
tings and controls.
ALARMS
ALARMS
