Chapter 7: Setting Up the System Defaults 7-5
Data Boxes
Data Boxes
Press the
SELECT BOXES
soft key to display the data box sub-menu. This allows
you to select up to 6 data boxes that you can display on the fishfinder.
Note: 1. A fixed set of nine of these data items are available for display in the
Nav Data half-screen window (see Chapter 2).
2. In addition to these grouped data boxes, boxes for the cursor readout, VRM/
EBL data, waypoint data, MOB data and simulator status are displayed when
selected or when the appropriate function is active.
3.Radar data is only repeated if the display is connected to an HSB series ra-
dar master display.
Data boxes provide regularly used data in a compact form so that most of the
picture can still be seen. The ones you select here can be turned on and off as a
group during normal operation, and you can also move them around the screen
individually using the context-sensitive cursor (see Context-Sensitive Cursor
Control on page 1-15.).
VARIATION SOURCE AUTO, MANUAL AUTO
BRIDGE NMEA HEAD-
ING
OFF or ON ON
CURSOR ECHO
RADAR CURSOR IN
CHART CURSOR IN
S/T CURSOR OUT
CURSOR ECHO LOCAL
OFF or ON
OFF or ON
OFF or ON
OFF or ON
OFF
OFF
OFF
ON
DATE FORMAT DD/MM/YY, MM/DD/YY MM/DD/YY
TIME FORMAT 12 HOUR, 24 HOUR 12 HOUR
TIME OFFSET UTC, or local offset value:
Plus or minus up to 12 hours,
in whole hours
UTC
LANGUAGE ENGLISH (UK), ENGLISH
(US), DANISH, FRENCH, GER-
MAN, DUTCH, ITALIAN, ICE-
LANDIC
NORWEGIAN, PORTU-
GUESE, SPANISH, SWEDISH,
FINNISH
ENGLISH (US)
SIMULATOR OFF, DATA, RADAR, BOTH OFF
Table 7-1: System Set Up Parameters
Menu Options Factory
Default
New
Default
