Chapter 5: Standard Chart Operations 5-29
Transferring
Waypoints and
Routes
CAUTION:
The function
COPY WPTS FROM HSB
replaces the existing waypoint and
route lists with the transferred lists.
➤ To receive incoming waypoints on SeaTalk or NMEA:
1. To display the waypoint list press MARKS followed by the
WAYPOINT LIST
soft key.
Press the
WAYPOINT TRANSFER
soft key.
2. Press the soft key
RECEIVE WPTS FROM ST/NMEA
.
The soft key changes to
STOP RECEIVING WAYPOINTS
.
When waypoints are transmitted by other equipment they are added to the
waypoint list on the chartplotter. Routes transmitted on NMEA are
appended to the route list.
3. To disable waypoint transfer, press the soft key
STOP RECEIVING WAY-
POINTS
.
Alternatively, press ENTER, or CLEAR, twice to close the Waypoint List.
➤ To send the waypoint list on NMEA:
1. Display the waypoint list as previously described, then press the
WAYPOINT
TRANSFER
soft key.
2. Press the soft key
SEND WPT LIST ON NMEA
.
The soft key changes to
STOP SENDING WAYPOINTS
.
The waypoint and route lists are transmitted from the chartplotter to other
instruments on NMEA.
➤ To receive the waypoint and route lists via HSB:
CAUTION:
Copying waypoints from another HSB instrument overwrites any
existing waypoint and route lists.
1. Display the waypoint list as previously described, then press the
WAYPOINT
TRANSFER
soft key.
2. Press the soft key
COPY WPTS FROM HSB
, you are prompted to confirm.
Press
NO
to cancel the operation, then ENTER if you wish to remove the
route list.
Press
YES
to continue. The waypoint list is transmitted to the chartplotter
from another instrument on HSB. Whilst the data is being transferred the
soft key is blanked; when the transfer is complete the soft key is re-dis-
played.
MARKS
WAYPOINT
LIST
WAYPOINT
TRANSFER
WAYPOINT
TRANSFER
WAYPOINT
TRANSFER
