1-6 HSB Series Color LCD Display
Operating Modes
Half -Screen Window Options
On a system with Radar, Chart and Fishfinder available, the following
information can be shown:
• Chart display (when in Fishfinder or Radar mode)
Fishfinder display (when in Chart mode):
Radar display (when in Chart mode):
If data is available, either as a function of the combined display unit or via
the HSB link, it can be displayed.
• CDI: This gives the Course Deviation Indicator graphical display, with
data relating to the target waypoint.
• BDI: This gives the Bearing and Distance Indicator graphical display, with
data relating to the target waypoint.
• Nav Data (Chart mode): This shows sixteen data boxes, providing navi-
gational data in the units specified in your set up. Note that up to 6 of these
data boxes are also available as a user-selectable group (see Section 7.3).
For details on the fishfinder, refer to the HSB Series Display Owner’s
Handbook supplied with your fishfinder.
Note: If you have an integrated system with a Pathfinder radar master display
that includes MARPA as a primary function, MARPA functionality is avail-
able on the repeater display.
Details on selecting windows are given in Chapter 2.
Table 1-1: Window Options for Combined/Integrated Systems
Full-screen
mode
Half-screen Window Options
Fishfinder Mode Depth/temp, Chart or CDI, BDI
Chart Mode CDI, BDI, Nav Data, Fishfinder or
Radar
Radar Mode CDI, BDI, Chart or Nav Data
Data Log Mode Windows not available
